HBZ A2217 3500KV Brushless Motor (보급형 브러쉬리스 모터)

- 저가형으로 많이 사용되는 브러쉬 리스 모터입니다.

- 3.5mm 골드커넥터가 기본 연결되어 있습니다.

Type: A2217

No. Of cells: 2-3 Li-Poly/ 6-10 Ni-Mh/Ni-Cd

RPM/V: 3500 RMP/V

Max. efficiency current:10-22A (>75%)

No load current / 10 V:0,7 A

Current capacity:32A/60 s

Internal Resistance: 84 mΩ

Dimensions:27.5x30 mm

Shaft diameter: 4 mm

Weight:72 g

Recommended model weight: g

Recommended prop without gearbox: APC 4.1x4.1

Includes:
1 x brushless motor
1 x cross type motor mount
1 x aluminum prop adapter
4 x countersunk screws

Test Data:

• GWS3500
• 11V 16.9A 7130 rpm, thrust 955 grams
• 10.5V 15.8A 6980 rpm, thrust 897 grams
• 10V 14.9A 6760 rpm, thrust 853 grams
• 9.5V 13.9A 6580 rpm, thrust 792 gram
