라디오마스터 ER6GV ELRS 2.4GHz PWM 수신기

RadioMaster ER6GV 2.4GHz ELRS PWM Receiver

- 라디오마스터 ER시리즈 6채널 PWM 수신기입니다.
- ExpressLRS 시스템을 기반으로 높은 신뢰성과 빠른 응답성을 자랑합니다.
- 고정밀 기압센서(Vario)가 내장되어 있습니다.
- 3.5~8.4V 입력전압과 3.0~26V의 배터리 전압 센서를 지원합니다.
- ExpressLRS 3.2 펌웨어가 기본 설치되어있습니다.
- 슬림한 수신기가 필요한 글라이더에 추천드립니다.

본 제품은 ELRS 전용 수신기 입니다.

4in1모듈이나 CC2500모듈에 사용하실 수 없습니다.

구성

수신기 1개

메뉴얼

The RadioMaster ER series of PWM receivers are based on the revolutionary ExpressLRS system.

It offers high performance, high reliability, flexible configuration, fast response speed and ultra-long range bringing you brand new experience with your hobby.

The ER6G & ER6GV receiver have been specially designed for glider pilots who require a compact and slim receiver.

It can drive up to 6 servos and has built-in receiver voltage telemetry and flight battery telemetry with the ability to automatically detect which voltage input to use.

Both ER6G & ER6GV feature a dual-antenna with telemetry power up to 50mw and can work stably with a 1S Lipo receiver battery.

The ER6G Receiver has the same functionality as the ER6GV only without a built in Vario for competitions that prohibit

the use of a Vario or simply for users who do not need a vario on their receiver.




Features
Based on the Revolutionary ExpressLRS System
High performance, high reliability, flexible configuration, fast response speed and ultra-long range
Support 6 PWM Channels
Optimized ground up PCB design
Automatically voltage telemetry of external battery voltage or built-in receiver voltage
ER6GV Receiver is built-in high-precision air pressure sensor (Vario)
Supports Wi-Fi updates and WEBUI configuration
High quality 2.54 mm connector
Standard 15 cm High Sensitivity Antenna
For fixed-wing aircraft and gliders
Compatible with all 2.4GHz ExpressLRS modules and transmitters with built in 2.4GHz ExpressLRS

Specification (ER6GV)
Item: ER6GV 2.4GHz ELRS PWM Receiver
Power supply: DC 3.5 - 8.4V
Antenna type: 15cm high sensitivity antenna
Wireless protocol: ExpressLRS 3.2 pre-installed
Output channel: 6CH PWM
Serial Output: CRSF / Sbus
Return power: maximum 50mw (LUA Adjustable)
Built-in high-precision air pressure sensor (Vario)
Battery voltage detection range: DC 3.0 - 26V
Weight: 5.0 grams
Dimensions: 42*13*8mm
Firmware: Device Category: Radiomaster 2.4Ghz / Device: RadioMaster ER6-GV 2.4GHz Diversity+6xPWM+Vario RX

Package Includes
1 * ER6GV 2.4GHz ELRS PWM Receiver
1 * Voltage telemetry wire (Type-A)
2 * Heat-shrink tube
1 * User Card
