라디오마스터 ER5C-i ELRS 2.4GHz PWM 수신기

RadioMaster ER5C-i 2.4GHz ELRS PWM Receiver

- 라디오마스터 ER시리즈 5채널 PWM 수신기입니다.
- ExpressLRS 시스템을 기반으로 높은 신뢰성과 빠른 응답성을 자랑합니다.
- 고감도 세라믹 안테나가 내장되어있어 안테나 와이어의 걱정이 없습니다.
- HV입력과 DC4.0~35V의 배터리 전압 센서를 지원합니다.
- ExpressLRS 3.3.0 펌웨어가 기본 설치되어있습니다.

- 자동차용 수신기로 추천드립니다.

본 제품은 ELRS 전용 수신기 입니다.

4in1모듈이나 CC2500모듈에 사용하실 수 없습니다.

구성

수신기 1개

메뉴얼

The RadioMaster ER5C-i receiver is based on the high-performance, revolutionary ExpressLRS system, featuring high reliability,

highly flexible configuration, ultra-fast response speeds, and an ultra-long receiving range, bringing with it a brand-new usage experience.

The ER5C-i ELRS receiver can drive up to 5 servos and has built-in receiver voltage telemetry and battery telemetry with the

ability to automatically detect which voltage input to use. The ER5C-i features a built-in high-sensitivity ceramic antenna,

it is designed for all types of surface models and provides a clean install without antenna wires to worry about.

Features
Built-in high-sensitivity ceramic antenna
Based on the Revolutionary ExpressLRS System
High performance, high reliability, flexible configuration, fast response speed and ultra-long range
Supports 5 PWM Channels
Automatically detects voltage telemetry of external battery voltage or receiver battery / ESC BEC voltage
Optimized ground up PCB design
Supports Wi-Fi updates and WEBUI configuration
Built-in a TCXO (temperature compensated crystal oscillator), ensures stable and accurate performance in any environment
Designed for all types of surface models
Compatible with all 2.4GHz ExpressLRS modules and transmitters with built in 2.4GHz ExpressLRS

Specifications
Item: ER5C-i 2.4GHz ELRS PWM Receiver
Power supply: DC 4.5 - 8.4V
Antenna type: Built-in high-sensitivity ceramic antenna
Wireless protocol: ExpressLRS 3.3.0 pre-installed
Output channel: 5CH PWM
Telemetry power: 10mW
Battery voltage detection range: DC 4.0 - 35V
Weight: 5.0 grams
Dimensions: 30.0*18.5*13.0 mm
Firmware: Device Category: Radiomaster 2.4Ghz / Device: RadioMaster ER5C-i

Package Includes
1 * ER5C-i 2.4GHz ELRS PWM Receiver
1 * Voltage telemetry wire
1 * User Card
