[ALIGN] 800 Aerial Fuselage(CQB) - 한정특가!

ALIGNRC T-Rex800E Aerial Fuselage

T-Rex800 Trekker를 위한 항공 촬영용 바디 세트.

Instructions:
●Special designed for T-REX 800E platform for aerial photography, fiberglass material, exterior rich sense of technology, features both light weight and high strength characteristics.
●Bright yellow color can effectively enhance identification in the sky, conducive to aerial photographic operation.
●Suitable for T-REX 800E Helicopter series.
●Quick disassembly design, as long as a few screws can fast install and remove for convenient to maintenance.
● Must be tied in with G800 Gimbal (H80B001XX), 800E Auxiliary battery mount set (H80T010XX), 800E Aerial Photography Landing Gear Assembly (H80F001XX).

주의 : CQB(Cheap Qualiy-Based Blemish) 제품은 하나하나 수공으로 제작되는 FRP 제품의 특성상 발생하는 미세한 스크래치, 땜빵 자국 등 양품으로 판매가 어려운 제품을 파격적인 특가에 판매하는 제품으로서 제품 성능(Performance)에는 문제가 없는 제품입니다. 표면 품질에 민감하신 분들은 오리지널 상품을 이용해 주시기 바랍니다.

●Body length:593mm
●Body width:247mm
●Body high:160mm
●Weight:Approx. 665g

●800E Aerial fuselage x 1
●Fuselage Support Aluminum Standoff A x 2(Φ8x39.5mm)
●Fuselage Support Aluminum Standoff B x 4(Φ8x28.5mm)
●Fuselage Support Aluminum Standoff C x 4(Φ8x41mm)
●Fuselage Support Aluminum Standoff D x 4(Φ8x29mm)
●Aluminum Standoff nutt x 4(Φ6xΦ8x1mm)
●Tail support Post x 2(Φ9.5x19.4mm)
●Socket screw x 4(M4x10mm)
●Socket screw x 2(M4x8mm)
●Socket Button Head Screw x 20(M3x6mm)
●M4 set screw x 4(M3x15mm)
●M3 set screw x 2(M4x12mm)
●Φ3File x 1
