5VDC로 동작하며, 2미터 이상의 측정거리에서 약 +/- 2.5cm 의 정확도를 가집니다.
I2C 및 PWM인터페이스를 가지고 있습니다.
특징
Resolution: 1 cm
Typical accuracy: +/- 2.5cm at distances greater than 2 meters (Refer to operating manual for complete operating specifications)
Range: 5cm to 40m
Update rate: Greater than 1kHz
Interface: I2C or PWM
Power (operating voltage): 4.75-5VDC; 6V Max
Current consumption: 65ma idle; 85ma during acquisition
Operating temperature: -20°C to 60°C
Laser wave length/Peak power: 905nm/1.3W
Beam divergence: 8m Radian
Optical aperture: 12.5mm
Water rating: IPX7
Unit dimensions: 24.5mm x 53.5mm x 33.5mm (1.0in x 2.1in x 1.3in)
Weight: 34g (1.2oz)
Note:CLASS 1 LASER PRODUCT CLASSIFIED EN/IEC 60825-1 2014. This product is in conformity with performance standards for laser products under 21 CFR 1040, except with respect to those characteristics authorized by Variance Number FDA-2016-V-2943 effective September 27, 2016.
