[Cubepilot] HerePro RTK GPS 모듈 (멀티밴드)

Name: [Cubepilot] HerePro RTK GPS 모듈 (멀티밴드)
Brand: CubePilot
SKU: QQ66071
Price: 1463000 KRW
Availability: OutOfStock

HerePro Multi-RTK

판매가격 : 1,463,000원

상품번호 : QQ66071
※문의시 상품번호를 알려주세요

재입고 요청하기

실시간 문의 (오전10시~오후6시)

이미지	상품명	선택

추가 옵션상품 총합계: 0원

옵션 상품을 포함하여 장바구니 담기 >

Specification

Features
Receiver type	184-channel u-blox F9P
GNSS systems	BeiDou, Galileo, GLONASS, GPS, QZSS
Satellite bands	BDS B1I B2I, GPS L1C/A L2C, GLONASS L1OF L2OF, GALILEO E1B/C E5b, QZSS L1C/A L2C
Maximum GNSS systems	4
Navigation update rate	Up to 20 Hz for RTK
Horizontal and vertical accuracy	RTK 0.01m +1ppm CEP
Heading accuracy	0.4 degrees
PVT horizontal positioning accuracy	1.5m CEP
Maximum altitude	50,000 m
Maximum speed	500 m/s
Convergence time	RTK < 10s
Acquisition	Cold starts 24s
	Aided starts 2s
	Reacquisition 2s
Sensitivity	Tracking & Navigation: –167 dBm
	Cold starts: –148 dBm
	Hot starts: –157 dBm
	Reacquisition: –160 dBm
Antenna	Multi-band dual antenna
Timepulse	Configurable from 0.25hz to 10mhz
Protocols	NMEA、UBX binary、RTCM 3.3
Anti-jamming	Active CW detection and removal
	Onboard band pass filter
Anti-spoofing	Advanced anti-spoofing algorithms
Pinout
Power (XT30)	x2

CAN FD	x2

USB / GPIO	x1 / x2

Others
SD card	16G
Flash	2M
RAM	1M
Input voltage	6 V - 40 V (maximum 60V)
Working Temperature	-40 °C to +85 °C
Size	15 x 78 mm
Weight	101g（without cable）
